RKPA 4-805 - Mini Power Single-Ended Cordset: 7/8", female, straight, 4-pin(3+PE), black body, 600 V, 15 A; TPE black cable, 14 AWG

(No reviews yet) Write a Review

SKU:: RKPA 4-805
UPC:
MPN:
Shipping:: Calculated at Checkout

$0.00

Current Stock:

Quantity:

Description
Additional Information

Description

Mini Power Single-Ended Cordset: 7/8", female, straight, 4-pin(3+PE), black body, 600 V, 15 A; TPE black cable, 14 AWG

Specifications

Product Family	Power Connector
Product Sub Family	7/8"
Connector Type	Cordset, single ended
Type of Contact / Gender	female
Connector Design	straight
Number of Pins	4(3+PE)
Shielding	Unshielded
Attachment Type	Coupling Nut
Rated Voltage (UL)	600 V
Rated Current (UL)*	15 A
Ambient Temperature (Operation)*	-30 °C to +90 °C
Protection Degree / IP Rating**	IP 67, IP 68

Materials

Contact Base Material	CuSn
Contact Plating	Ni/Au
Contact Bearer Material	PVC
Contact Bearer Color	black
Molded Body Material	PVC
Molded Body Color	black
Attachment Material	CuZn

Cable Data

Cable Number	805
Conductor Size	14 AWG
Number of Wires	4
Cable Jacket Material	TPE
Cable Jacket Color	black
Cable Diameter D	ø 0.390"
Wire Insulation Material	PVC/NYLON
Ambient Temperature (Fixed Installation)	-30 °C to +90 °
Flammability Class (Cable Jacket)	FT-4

Approvals

UL-File	E482233
UL	TC-ER

Safety & Environmental Compliance

RoHS Compliant	Yes

Resistances

Oil Resistance	Oil Res I/II
UV Resistance	Sunlight Res

Notes

Protection Degree / IP Rating Note	** only if mounted and locked in combination with Hirschmann / Lumberg Automation connector.

Documentation

View AllClose

Additional Information

Variant_Options:	Item #\|Item Description\|Cable Length
Variant_Options 511000326:	511000326\|RKPA 4-805/0.5M\|0.5 m
Variant_Options 511000327:	511000327\|RKPA 4-805/1M\|1 m
Variant_Options 511000329:	511000329\|RKPA 4-805/2M\|2 m
Variant_Options 511000331:	511000331\|RKPA 4-805/3M\|3 m
Variant_Options 511000332:	511000332\|RKPA 4-805/4M\|4 m
Variant_Options 511000333:	511000333\|RKPA 4-805/5M\|5 m
Variant_Options 511000334:	511000334\|RKPA 4-805/6M\|6 m
Variant_Options 511000335:	511000335\|RKPA 4-805/8M\|8 m
Variant_Options 511000336:	511000336\|RKPA 4-805/10M\|10 m
Variant_Options 511000337:	511000337\|RKPA 4-805/12M\|12 m
Variant_Options 511000338:	511000338\|RKPA 4-805/14M\|14 m
Variant_Options 511000339:	511000339\|RKPA 4-805/15M\|15 m
Variant_Options 511000340:	511000340\|RKPA 4-805/18M\|18 m
Variant_Options 511000341:	511000341\|RKPA 4-805/20M\|20 m
Variant_Options 511000342:	511000342\|RKPA 4-805/22M\|22 m
Variant_Options 511000343:	511000343\|RKPA 4-805/25M\|25 m
Variant_Options 511000344:	511000344\|RKPA 4-805/30M\|30 m
Variant_Options 511000345:	511000345\|RKPA 4-805/35M\|35 m
Variant_Options 511000346:	511000346\|RKPA 4-805/40M\|40 m
Variant_Options 511000347:	511000347\|RKPA 4-805/45M\|45 m
Variant_Options 511000348:	511000348\|RKPA 4-805/50M\|50 m
Variant_Options 511000877:	511000877\|RKPA 4-805/80M\|80 m
Variant_Options 511000328:	511000328\|RKPA 4-805/1.5M\|1.5 m
Variant_Options 511000330:	511000330\|RKPA 4-805/2.5M\|2.5 m
